PN 311 701 (HU) 3/2-es pneumatikus vezérlésű NAMUR szelep, monostabil
(HU) 3/2-es pneumatikus vezérlésű NAMUR szelep, monostabil - alaph.zárt - G1/4"
It is possible to record custom requests on the order summary page.
| Actuation: | Pneumatically actuated |
|---|---|
| Actuation pressure: | 3…10 bar |
| Air flow rate (P1=6 bar, ΔP=1 bar): | 1250 l/min |
| Function: | Monostable |
| Material body: | Aluminum |
| Medium: | Compressed air |
| Mounting type: | In-line |
| Operating pressure: | 3…10 bar |
| Port orientation: | On two sides |
| Port size: | G 1/8" |
| Port size / Connection: | G 1/4" |
| Temperature range: | -10°C…+50°C |
| Ways: | 3/2-ways |
PN 311 701
(HU) 3/2-es pneumatikus vezérlésű NAMUR szelep, monostabil - alaph.zárt - G1/4"
| Product number | Actuation pressure | Air flow rate (P1=6 bar, ΔP=1 bar) | Function | Operating pressure | Port size | Port size / Connection | Options |
|---|
